Vehicle Specific 18 Console For 2002 2023 Chevrolet G Series Or GMC Savana Van

Special Order Item

Features:

• 18" vehicle-specific console for 2002-2023 Chevrolet G-Series or GMC Savanna van Model
• Easy to install
• No permanent modification required
• Designed to mount to vehicle floor surface
• No vehicle mounting kit required
• 14 gauge formed steel housing with extruded aluminum top frame
• Includes filler plates (FP) and/or equipment brackets (EB) to completely enclose mounting area less internal mount options
• Ships motor freight when ordering 2 or more
• Does not work with C-HDM-107 computer mount
• For gas engine van only, does not work in diesel engine van

Specifications:

• Overall measurements: 9" high x 9" wide x 28.25" long (including forward trim panel)
• Height: 19"
• Width at engine cover: 17"
• Width at face (controls): 13.5"
• Depth for controls: top= 9", middle= 12", bottom=4"
• Console top platform: 8.5" x 13.5" wide (tapers out to 17")
• Extends out from engine cover at - FLOOR: 20"
• Gross weight: 28 lbs

Informational Links:

• Written Product Specs (PDF)
• Isoview Drawing (JPG)

Sales staff will reach out to obtain equipment information.
