Whelen Hands Free Siren with 9 Switch Lights

The 295SLSA6 Hands-Free Siren is a Single Unit Siren with 9-Switch Light Control and Standard Switching, with Park Kill & Timed Out Relay with 17 Scan-Lock™ Siren Tones. Each of the 6 push buttons activate one 10 amp output. Slide switch activates a 20 amp circuit, and can be wired, via a dip switch to control a 3 position program pattern. The 6th position push button may be dip switch set for momentary, 8 second timer, latch-on/latch-off, or flasher modes. Most high current applications such as strobe power supplies, headlight and brakelight flashers can be controlled by the 295HFSA6.

Features:

• "Park-Kill" feature disables the siren tone when the vehicle is in park
• Timed-Out Relay for shotgun lock, trunk lock, etc
• Six function siren plus radio repeat and public address
• Four position slide switch & six push-on/push-off switches (one momentary)
• Selectable 100 or 200 watt output, standard
• Slide switch and push buttons control nine state-of-the-art, internal high-current solid-state drivers
• Push-button switches control secondary functions
• Each slide switch position has different colored LED "On" indicator
• Push button switches have a green/red LED indicator for operating status display
• Choice of 36 press-on legend tabs
• SI Test®, a silent self-diagnostic feature which provides real time indication of proper siren/speaker operation
• Two different diagnostic tests include: Continuous dynamic testing during normal siren operations and silent testing while "radio" mode with the "manual" button depressed
• Dimensions: 6" W x 3.25" H x 6.75" D
